FANUC Series 30i/31i/32i -A, 31i - A5
GRINDING CANNED CYCLE
(FOR GRINDING MACHINE)
041118
FANUC Series 30i/31i/32i -A, 31i -A5
GRINDING CANNED CYCLE (FOR GRINDING MACHINE)
１．Type of applied technical documents
Name
FANUC Series 30i/300i/300is –MODEL A
FANUC Series 31i/310i/310is –MODEL A
FANUC Series 31i/310i/310is –MODEL A5
FANUC Series 32i/320i/320is –MODEL A
PARAMETER MANUAL
Spec.
No./Version
B-63950EN/02
２．Summary of Change
Group Name/Outline
New, Add
Correct,
Delete
Applicable
Date
Basic
Function
Optional
Function
This function is the canned cycle for the
grinding machine.
Add Immediate
Unit
Maintenance
Parts
Notice
This function is available in the following CNC control software.
FANUC Series 30i/300i/300is -MODEL A G002, G012, G022/5.0 or later
FANUC Series 31i/310i/310is -MODEL A G101, G111/5.0 or later
FANUC Series 31i/310i/310is -MODEL A5 G121, G131/5.0 or later
FANUC Series 32i/320i/320is -MODEL A G201/5.0 or later
Correction
Another
Previous page
Next page
