B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 73 -
1423 Feedrate in manual continuous feed (jog feed) for each axis
[Input type] Parameter input
[Data type] Real axis
[Unit of data] mm/min, inch/min, degree/min (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] Refer to the standard parameter setting table (C)
(When the increment system is IS-B, 0.0 to +240000.0)
(1) When JRV, bit 4 of parameter No.1402, is set to 0 (feed per
minute), specify a jog feedrate (feed per minute) under an
override of 100%.
(2) When JRV, bit 4 of parameter No.1402, is set to 1 (feed per
revolution), specify a jog feedrate (feed per revolution) under an
override of 100%.
NOTE
This parameter is clamped to the axis-by-axis
manual rapid traverse rate (parameter No. 1424).
1424 Manual rapid traverse rate for each axis
[Input type] Parameter input
[Data type] Real axis
[Unit of data] mm/min, inch/min, degree/min (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] Refer to the standard parameter setting table (C)
(When the increment system is IS-B, 0.0 to +240000.0)
Set the rate of manual rapid traverse when the rapid traverse override
is 100% for each axis.
NOTE
1 If 0 is set, the rate set in parameter 1420 (rapid
traverse rate for each axis) is assumed.
2 When manual rapid traverse is selected (bit 0 (RPD)
of parameter No. 1401 is set to 1), manual feed is
performed at the feedrate set in this parameter,
regardless of the setting of bit 4 (JRV) of parameter
No. 1402.
1425 FL rate of the reference position return for each axis
[Input type] Parameter input
[Data type] Real axis
[Unit of data] mm/min, inch/min, degree/min (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] Refer to the standard parameter setting table (C)
(When the increment system is IS-B, 0.0 to +240000.0)
Set feedrate (FL rate) after deceleration when the reference position
return is performed for each axis.
