4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 144 -
Example) When the axis name is X, a subscript is added as
indicated below.
Setting value Axis name displayed on a screen such as the
position display screen
0 X
1 X1
77 XM
83 XS
If a multi-path system is used, no extended axis name is used within a
path, and no subscript is set for the axis names, then the path number
is automatically used as the subscript for the axis names. To disable
the display of axis name subscripts, set a blank (32) of ASCII code in
the parameter for specifying an axis name subscript.
NOTE
If an extended axis name is used even for one axis
within a path, the use of an axis name subscript
becomes impossible within the path.
3132 Axis name (absolute coordinate) for current position display
[Input type] Parameter input
[Data type] Byte axis
[Valid data range] 0 to 255
These parameters set the axis name for current position display.
When G code system B or C is used, the axis name set in parameter
No.3132 is used for both absolute and relative coordinate axes.
The values set in these parameters are used only for display.
When 0 is set in this parameter, the setting of parameter No. 1020 is
used.
When an extended axis name is used, only the first character displayed
is replaced.
3133 Axis name (relative coordinate) for current position display
[Input type] Parameter input
[Data type] Byte axis
[Valid data range] 0 to 255
These parameters set the axis name for current position display.
When G code system B or C is used, the axis name set in parameter
No.3132 is used for both absolute and relative coordinate axes.
The values set in these parameters are used only for display.
When 0 is set in this parameter, the setting of parameter No. 1020 is
used.
When an extended axis name is used, only the first character displayed
is replaced.
