4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 172 -
1: Not set as a search directory.
# 1 MC2 MTB dedicated directory 2 "//CNC_MEM/MTB2/" of the initial
directories is:
0: Set as a search directory.
1: Not set as a search directory.
# 2 MC1 MTB dedicated directory 1 "//CNC_MEM/MTB1/" of the initial
directories is:
0: Set as a search directory.
1: Not set as a search directory.
# 3 SYS The system directory "//CNC_MEM/SYSTEM/" of the initial
directories is:
0: Set as a search directory.
1: Not set as a search directory.
# 7 SCF A search folder is:
0: Not added.
1: Added.
When a search folder is added, a search is made in the following
order:
1) Folder where the main program is stored
2) Common program folder, which is an initial folder
3) MTB-dedicated folder 2, which is an initial folder
4) MTB-dedicated folder 1, which is an initial folder
5) System folder, which is an initial folder
The folders of 3) through 5) can be excluded from search target
folders by setting the parameters MC2, MC1, and SYS.
3460 Second auxiliary function specification address
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 65to67, 85to87
Specify which of A, B, C, U, V, and W is to be used as the address for
specifying the second auxiliary function. If an address used as an
axis name is specified, the second auxiliary function is disabled.
Name
A B C U V W
Setting value
65 66 67 85 86 87
Address B is assumed when a value other than the above is set.
However, the name U, V, or W can be used with the T series only
when G code system B or C is used. When a value from 85 to 87 is
specified with G code system A, the specification address for the
second auxiliary function is B.
3471
Allowable difference between the specified end position and the end
p
osition obtained from the increase/decrease and fre
q
uenc
y
in s
p
iral
