B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 475 -
4.68 PARAMETERS OF DISPLAY AND EDIT (2 OF 2)
#7 #6 #5 #4 #3 #2 #1 #0
13102 EDT
[Input type] Parameter input
[Data type] Bit path
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
# 7 EDT During memory operation, program editing is:
0: Enabled.
1: Disabled.
NOTE
1 When 0 is set, during memory operation, you can
stop the program by a single block stop or feed
hold, select the EDIT mode, and edit the program.
When the main program is running:
- The same edit functions as used for ordinary
editing can be used.
When a subprogram is running:
- Only the word-unit edit function can be used.
- Any program called from DNC or MDI operation
cannot be edited.
- Only the subprogram can be edited.
2 Before restarting memory operation, take extreme
caution to return the cursor to the position before
stopping the program. If you want to execute the
program from other than the cursor position when
stopped, be sure to reset the machine before
executing the program.
#7 #6 #5 #4 #3 #2 #1 #0
13112 NTD NTA SPI SVI IDW
[Input type] Parameter input
[Data type] Bit path
# 0 IDW Editing on the servo or spindle information screen is:
0: Prohibited.
1: Not prohibited.
# 1 SVI The servo information screen is:
0: Displayed.
1: Not displayed.
