4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 312 -
:
G99.9 → O2099
When the setting of parameter No. 6041 is changed to -900, the
same set of custom macro calls (modal calls) is defined.
NOTE
1 When the following conditions are satisfied, all calls
using these parameters are disabled:
1) When a value not within the specifiable range is
set in each parameter
2) (Value of parameter No.6042 + value of
parameter No.6043 - 1) > 9999
3) When bit 0 (DPG) of parameter No. 6007 = 0 (to
disable calls using G codes with a decimal point)
2 The specification of a mixture of simple calls and
modal calls is not allowed.
3 If a range of G codes set by these parameters
duplicate G codes specified in parameter No.6060
to No.6069, the calls specified by parameter
No.6060 to 6069 are made preferentially.
6044 Start M code used to call a subprogram
[Input type] Parameter input
[Data type] 2-word path
[Valid data range] 3 to 99999999
6045 Start program number of a subprogram called by M code
[Input type] Parameter input
[Data type] 2-word path
[Valid data range] 1 to 9999
6046
Number of M codes used to call subprograms (number of subprograms
called by M codes)
[Input type] Parameter input
[Data type] 2-word path
[Valid data range] 0 to 32767
Set this parameter to define multiple subprogram calls using M codes
at a time. With M codes as many as the value set in parameter No.
6046 starting with the M code set in parameter No. 6044, the
subprograms of program numbers as many as the value set in
parameter No. 6046 starting with the program number set in 6045 can
be called. Set 0 in parameter No. 6046 to disable this mode of calling.
Example)
When parameter No. 6044 = 80000000, parameter No. 6045 =
3000, and parameter No. 6046 = 100 are set, a set of 100
subprogram calls is defined as follows:
