4.77 PARAMETERS OF NANO SMOOTHING
19581 Tolerance smoothing for nano smoothing
[Input type] Setting input
[Data type] Real path
[Unit of data] mm, inch, degree (input unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] 0 or positive 9 digit of minimum unit of data (refer to the standard
parameter setting table (B) )
(When the increment system is IS-B, 0.0 to +999999.999)
This parameter sets a tolerance value for a program created using
miniature line segments in nano smoothing.
When 0 is set in this parameter, a minimum amount of travel in the
increment system is regarded as a tolerance value.
19582
Minimum amount of travel of a block that makes a decision based on an
angular difference between blocks for nano smoothing
[Input type] Setting input
[Data type] Real path
[Unit of data] mm, inch, degree (input unit)
[Minimum unit of data] Depend on the increment system of the reference axis
[Valid data range] 0 or positive 9 digit of minimum unit of data (refer to the standard
parameter setting table (B) )
(When the increment system is IS-B, 0.0 to +999999.999)
This parameter sets the minimum amount of travel of a block that
makes a decision based on an angular difference between blocks for
nano smoothing. A block that specifies an amount of travel less than
the value set in this parameter makes no decision based on an angular
difference.
When 0 is set in this parameter, a decision based on an angular
difference is made with all blocks.
A value greater than the value set in parameter No. 8490 for making a
decision based on the minimum travel distance of a block must be set.
