3.CREATING AND EDITING SEQUENCE PROGRAMS B-66234EN/05

- 74 -

3.5.17.2 Soft key

The address, the symbol and the functional instruction in ladder

diagram can be searched by the soft key. Two modes of operation can

be chosen by the following check of the option screen: From the

[Tool] menu, choose [Options], then click [Ladder] tab.

Table 3.5.17.2

Setting Shortcut key Soft key display Explanation

[F2]

Down Coil Search The address and the symbol of the cursor position are

taken in, and the downward coil of cursor is searched.

[F3]

Down Search The downward contact, coil and functional instruction

of cursor are searched using the conditions inputted in

the search screen.

[Shift]+[F2]

Up Coil Search The address and the symbol of the cursor position are

taken in, and the upward coil of cursor is searched.

[Shift]+[F3]

Up Search The upward contact, coil and functional instruction of

cursor are searched using the conditions inputted in

the search screen.

[Ctrl]+[F2]

Global Search The search range changes the global or the local.

No check

[Ctrl]+[F3]

Search Address The address and the symbol of the cursor position are

taken in.

[F2]

Down Coil Search The address and the symbol of the cursor position are

taken in, and the downward coil of cursor is searched.

[F3]

Down Search The address, the symbol and the functional instruction

of the cursor position are taken in, and the downward

coil of cursor is searched.

[Shift]+[F2]

Up Coil Search The address and the symbol of the cursor position are

taken in, and the upward coil of cursor is searched.

[Shift]+[F3]

Up Search The address, the symbol and the functional instruction

of the cursor position are taken in, and the upward coil

of cursor is searched.

Check

[Ctrl]+[F2]

Global Search The search range changes the global or the local.
