D.MULTI-LANGUAGE PMC MESSAGE CREATION TOOL APPENDIX B-66234EN/05

- 490 -

[Example-3]

Create a source file “multi_msg.txt” from a multi-language PMC

message file “msg_mcard”.

- Command

[Example-4]

Create a source file “multi_msg.txt” with Unicode (UTF-16) from a

multi-language PMC message file “msg_mcard”.

- Command

Multi-language PMC message text file (ANSI)

(multi_msg.txt)

%@4-D

“Create：11-Dec-2003 Edition：0002

Multi-language message English / German / Japanese”

$0 %A000.1 1002 EXT. EMERGENCY STOP SIGNAL

$0 ALM1001 1001 FUSE IS BLOWN (SURGE KILLER)

$0 %P3.ALM1003 1003 EMERGENCY STOP

$1 %A000.1 1002 外部非常停止になりました

$1 ALM1001 1001 ﾋｭｰｽﾞ切れ(ｻｰｼﾞｷﾗｰ)

$1 %P3.ALM1003 1003 非常停止です

$2 %A000.1 1002 EXT. EMERGENCY STOP SIGNAL

$2 ALM1001 1001 FUSEIS BLOWN (SURGE KILLER)

%P3.

ALM1003

1003

TIME

@0DB

01@

VER(M100

M109)

 cd \pmc_message

 fmsgcnv msg_mcard /o=multi_msg.txt



1st-path PMC

multi-language

PMC message file

(msg_mcard)

Multi-language PMC message text file (Unicode)

(multi_msg.txt)

%@4-D

“Create：11-Dec-2003 Edition：0002

Multi-language message English / German / Japanese”

$0 %A000.1 1002 EXT. EMERGENCY STOP SIGNAL ON

$0 ALM1001 1001 FUSE IS BLOWN (SURGE KILLER)

$0 LEVEL2.ALM1003 1003 TIME OVER(M100-M109)

$1 %A000.1 1002 外部非常停止になりました

$1 ALM1001 1001 ﾋｭｰｽﾞ切れ(ｻｰｼﾞｷﾗｰ)

$1 LEVEL2.ALM1003 1003 ﾀｲﾑｵｰﾊﾞｰ (M100-M109)

$2 %A000.1 1002 EXT. EMERGENCY STOP SIGNAL

$2 ALM1001 1001 FUSEIS BLOWN. (SURGE KILLER)

$2 LEVEL2.ALM1003 1003 TIME ÕVER(M100-M109)

 cd \pmc_message

 fmsgcnv msg_mcard /unicode /o=multi_msg.txt



3rd-path PMC

multi-language

PMC message file

(msg_mcard)
