FAPT Ladder-III Operators manual Page 408

Operators manual
10.COMMAND LINE EXECUTION FUNCTION B-66234EN/05
- 382 -
Message Cause/action
A:E-6020
Memory card format file not found.
The memory card format file does not exist in the *.LAD file. Execute
the compilation.
A:E-6021
Password is insufficient
Insufficient password.
A:E-6022
Read only attribute file xxx is already exists.
Since the attribute of xxx file is read-only, the contents cannot be
changed.
A:E-6023
Folder xxx is already exists.
Since the attribute of xxx folder is read-only, the contents cannot be
changed.
A:E-6024
Cannot open xxx file.
The contents cannot be written in xxx file.
Please confirm the attribute of xxx file and the attribute of the folder.
A:E-6026
New lad file name is illegal.
- The LAD file cannot be created, if a file with the same name already
exists.
- *.LAD is not specified as the extension of a file name.
Please check that the extension of the LAD file name is *.LAD.
A:E-6027
Two or more same parameters were
specified.
- Two or more "/Pmctype" option or "/ioexp" options ware specified.
Please confirm the option setup.
A:E-6028
Cannot create new LAD file.
- Cannot create new LAD file. The place that you saved is
write-protected.
A:E-6029
Existing Lad file name is illegal.
- There is no specified LAD file.
A:E-6030
It is necessary to decompile LAD File.
- There is an older source program than memory card format file.
Please decompile memory card format file and update a source file.
A:W-7004
Duplicate symbol data items defined for the
same address were detected. (****items)
**** duplicate symbol data items defined for the same address were
detected. Either source data or memory card data is valid according to
the setting of the symbol merge option.
(Detail log is not output.)
A:W-7004
Duplicate symbol data items defined for the
same address were detected.
(address ***)
duplicate symbol data items defined for the same address were
detected. Either source data or memory card data is valid according to
the setting of the symbol merge option. (Detail log is output.)
A:W-7005
Same symbol exists. (**** items)
**** symbols which had been defined were found.
The symbol data deletes the symbol in no priority by the option setting
about the symbol merging.
(Detail log is not output.)
A:W-7005
Same symbol exists. (address **** symbol
****)
The symbol character string defined in the symbol data at address
****/symbol **** is already defined at another address.
The symbol data deletes the symbol in no priority by the option setting
about the symbol merging.
(Detail log is output.)
A:W-7006
The number of symbol data exceeds the limit.
*** items were not merged.
During symbol data merge processing, the total number of data
exceeded the maximum allowable value defined with the system. Data
beyond the symbol data is not output to the source program. (Detail
log is not output.)
A:W-7006
The number of symbol data exceeds the limit.
*** address were not merged.
During symbol data merge processing, the total number of data items
at address ****/symbol **** exceeded the maximum allowable value
defined with the system. Data beyond the symbol data is not output to
the source program. (Detail log is output.)
"Command File Name" batch command start. Beginning of command file execution.
Batch command completed. Batch command completed
