FAPT Ladder-III Operators manual Page 340

Operators manual
9.DIAGNOSIS B-66234EN/05
- 314 -
2. To select the language of monitor screen, click [Ladder Diagram]
or [Mnemonic].
3. When pressed <OK> button or <Apply> button, the language of
monitor screen is settled.
NOTE
The following screens are always displayed with
ladder language
• Collective display
• Search results list display
Mnemonic monitor screen
This section describes the procedure for displaying a mnemonic
monitor screen.
Procedure
1. Select [View] - [Program List]. The [Program List] screen
appears. (Usually, this screen appears automatically when a LAD
file is created or opened.)
2. Check the current programmer mode (offline or online). If the
programmer mode is offline, select [Ladder] – [Programmer
Mode] –[Online] or click <Online/Offline change> button to
change the programmer mode to online.
3. Check the current ladder mode (monitor or editor). If the ladder
mode is editor, select [Ladder] – [Ladder Mode] –[Monitor] or
click <Ladder Monitor> button to change the ladder mode to
monitor.
4. On the [Program List] screen, double-click the ladder program
you want to monitor. Alternatively, select the ladder program and
press the [Enter] or [F10] key.
