B-66234EN/05 13.ERROR MESSAGES

- 463 -

Error code Message Cause/action

K: E-3202 Automatic assignment of the address was

unsuccessful.

Compile the ladder and perform automatic address

assignment.

K:E-6001 Cannot be handle data type '%@2-D'.

K:E-6101 The address of symbol is undefined.

K:E-6201 The limitation character is used for the symbol.

K:E-6202

This functional instruction cannot use the local

symbol.

K:E-6301 The address of symbol is undefined.

K:W-4100 Comment data not found.

Data consisting of symbols only was converted to an

address.

K:W-4101 Data not found.

System parameters, message data, title data,

symbols/comments, and I/O module data are not found.

K:W-4102 Deleted KANJI characters.

K:W-4103 Expected control condition(s). No control condition is set for a function instruction.

K:W-4104 Illegal characters are specified at ****. Invalid data was specified in ****.

K:W-4105

Illegal OP.PANEL( PARAMETER ). Proceed to

convert with using 'NO'.

The system parameter OP.PANEL (parameter) is invalid.

Conversion is performed assuming "NO."

K:W-4106 Illegal symbol.

The symbol data does not satisfy the standard (check

level-1).

(FORMAT-C)

K:W-4108

Include KANA or KANJI character(s) in

comment data.

Comment data including full-size characters was converted

without selecting the full-size character conversion option (J

option).

K:W-4109 Logical operated with unused register(s).

An operation was performed with a register not entered in

the ladder data.

K:W-4110 Logical product remains in register(s). A register was not output to ladder data.

K:W-4111

Message data include KANA OR KANJI

characters at ****.

Message data **** includes full-size/half-size katakana

characters.

K:W-4112 Not enough control condition(s).

Not all necessary control conditions are set for a function

instruction.

K:W-4113 Not found data at **** address. At address ****, no message is defined.

Not found parameter numbered ****.

K:W-4114

Not found title numbered $.

K:W-4116 Not found **** PMC-OS file..

K:W-4117 Not used net comment pointer exist. $

K:W-4118 Output unused register(s).

K:W-4119 Overwrote existing data.

K:W-4120 Invalid qualifier.

An invalid character follows the end ID code (%) of each

data item (system parameter, message data, title data,

ladder, symbol/comment, and I/O module data).

K:W-4121 Registers overflow.

K:W-4122

Some garbage data are found at end of ladder

data.

Upon conversion to FORMAT-B, data that does not belong

to the first to third levels or any sub-programs was found.

This message is output when data is found after the last

SPE instruction.

K:W-4123 Specify same group base and slot.

In the I/O module data, the same number is specified for

group, base, and slot data.

K:W-4124

Specify same number( Group ) at I/O UNIT-B

as I/O UNIT-A.

K:W-4125

Specify the value( Base ) except 0 at I/O

UNIT-B.
