B-66234EN/05 APPENDIX D.MULTI-LANGUAGE PMC MESSAGE CREATION TOOL

- 481 -

D.1.2 Usable Characters

The types of characters usable in message text vary depending on the

PMC model. See the following table for details.

Table D.1.2(a)

Characters that can be entered

Alphabetical

characters

Japanese characters

PMC

Numerical

characters

Upper

case

Lower

case

JIS level-1/-2

kanji set

Half-size

kana

European

special

characters

Simplified

Chinese

characters

Korean

(Hangul)

characters

30i-A PMC

30i-A PMC(EXT)

30i-A PMC(2ND)

30i-A PMC(2ND, EXT)

30i-A PMC(3RD)

30i-A PMC(3RD, EXT)

31i-A PMC

31i-A PMC(EXT)

31i-A PMC(2ND)

31i-A PMC(2ND, EXT)

31i-A PMC(3RD)

31i-A PMC(3RD, EXT)

32i-A PMC

32i-A PMC(EXT)

32i-A PMC(2ND)

32i-A PMC(2ND, EXT)

32i-A PMC(3RD)

32i-A PMC(3RD, EXT)

A A A B A B A B

A: Usable

B: Some characters cannot be displayed on CNC side. Multi-language PMC message creation tool cannot check

whether they can be displayed.

(a) Input method of European special characters

(i) Direct input (Only when the encoding of a text file is

Unicode.)

(ii) Code input

Please input the code of european special character between

@0D and 01@.

Ex.) TIME @0DB101@VER

About the code of European special characters, please see “Table

D.1.2(b)”

(b) Input method of JIS level1/2 kanji set

(i) Direct input using Japanese IME

(ii) Code input

Please input JIS code between @02 and 01@.

Ex 0248733E6F44643B5F01@
