B-66234EN/05 3.CREATING AND EDITING SEQUENCE PROGRAMS

- 93 -

3. Wild card

3-1 Asterisk (*)

The following types of wildcard replacement using asterisks

are available:

Character string to be replaced with

Y200 Y* Y200.1 Y*.1 Y200.*

X100 A B B B B

X* A B B B B

X100.0 B B A B B

X*.0 B B A C A

Character

string to be

searched for

X100.* B B A A A

A : Can be replaced.

B : Cannot be replaced.

C : Can be replaced only when the signal names are the

same.

(Example) X*.0 → X*.1

The following types of wildcard specifications are not

available:

X1* X1*1 X*1 X*1*

X1*.0 X1*1.0 X*1.0 X*1*.0

X1*.* X1*1.* X*1.* X*1*.*

X*.* *.*

3-2 Question (?)

The following types of wildcard replacement using question

marks are available:

Can be replaced. Cannot be replaced.

X0??0 → Y0??0 X0??0 → Y0?00

X0??0 → Y0?0?

X0??0 → Y0???

X0??0 → Y0??0.0

X0??0.0 → Y0??0.0 X0??0.0 → Y0??0.?

X0??0.0 → Y0??0

NOTE

1 Address P can be replaced with another character

string only in the CALL and CALLU instructions.

2 No wildcards can be used for replacing an address

using a symbol.

3 No wildcards can be used in a signal name.
