FAPT Ladder-III Operators manual Page 365

Operators manual
B-66234EN/05 9.DIAGNOSIS
- 339 -
3. Click the <Parameter> button.
The [Signal Trace Parameter] screen appears.
4. Set data on the [Signal Trace Parameter] screen.
See Subsection 9.6.6, "[Signal Trace Parameter] Screen."
5. Click the <Start> button. The <Start> button enters the down
state, and signal tracing starts.
6. To terminate tracing, click the <Start> button again. The <Start>
button then enters the up state, and signal tracing terminates.
• Signal status indication
The signal is off.
The signal is on.
• Mask bit name indication
The numbers of the bits to be detected are indicated with
bold characters.
The numbers of the bits not to be detected are indicated
with grayed characters.
Example: When the signals on bits 4 to 7 are detected, and
bits 0 to 3 are masked
R9028
7 6 5 4 3 2 1 0
9.6.2 Toolbar
Fig. 9.6.2
<1> Parameter
<2> Start and stop of tracing
<3> Symbol indication
<4> Number search
<5> Combo box for inputting the character string for number search
<Parameter button>
<Start button>
<1> <2> <3> <4> <5>
