FAPT Ladder-III Operators manual Page 288

Operators manual
6.MNEMONIC EDITING B-66234EN/05
- 262 -
6.4.2 Title
%@1
01 MACHINE TOOL BUILDER NAME
02 MACHINE TOOL NAME
03 CNC & PMC NAME
04 PMC PROGRAM NO.
05 EDITION NO.
06 PROGRAM DRAWING NO.
07 DATE OF PROGRAMMING
08 PROGRAM DESIGNED BY
09 ROM WRITTEN BY
10 REMARKS
%
6.4.2.1 Symbol and comment
%2-C
%@2-C
R0200.0 UNIT-3-POWER
$1 ‘KEEP POWER ON’ ‘KEEP UNIT-3 POWER ON’
R0200.1 UNIT-2-ACT
$1 ‘$’POWER$$’ ‘KEEP UNIT-4 $$POWER$’ ON’
R0300.0
$1 ‘KEEP POWER ON’ ‘KEEP UNIT-4 POWER ON’
P0008 OPEN-FRONT
$1 ‘OPEN FRONT COVER
L0100 INITIALIZE
$1 ‘’ ‘INITIALIZE OF SEQUENCE
%
NOTE
1 Symbol is up to 16 characters (bytes).
2 Relay comment is up to 16 characters (bytes).
3 Comment is up to 30 characters (bytes).
%2-C2
%@2-C2
R0200.0 UNIT-3-POWER
$1 ‘KEEP POWER ON’ ‘KEEP UNIT-3 POWER ON’
R0200.1 UNIT-2-ACT
$1 ‘$’POWER$$’ ‘KEEP UNIT-4 $$POWER$’ ON’
R0300.0
$1 ‘KEEP POWER ON’ ‘KEEP UNIT-4 POWER ON’
P0008 OPEN-FRONT
$1 ‘OPEN FRONT COVER
L0100 INITIALIZE
$1 ‘’ ‘INITIALIZE OF SEQUENCE
%
NOTE
1 Symbol is up to 16 characters (bytes).
2 First Comment and second comment are up to 30
characters (bytes).
A
ddress
Relay comment
Coil comment
Symbol
Mark that represents
comment data
A
ddress
1st comment
2nd comment
S
y
mbol
Mark that represents
comment data
