B-66234EN/05 13.ERROR MESSAGES

- 451 -

Error code Message Cause/action

The online edit/input/output function (sequence program

load/store) is protected. Check the keep relay.

E:E-6183 This function is protected.

Display of the data table control screen is protected. Check

the keep relay.

E:E-6187 Write protect. The signal status is write-protected. Check the keep relay.

E:E-6197 INPUT NET TOO LARGE

E:E-6362

Ladder diagram on the PMC side is being

edited now.

E:E-6701

The type of symbol specified as basic

instruction is erroneous.

E:E-6702

The output prohibition symbol was specified as

the coil.

E:E-6703

The type of symbol specified as functional

instruction is erroneous.

E:E-6704

The output prohibition symbol was specified as

the functional instruction.

E:E-6705

The symbol of incorrect type was specified as

the functional instruction.

E:E-6706 The address of symbols undefined.

E:E-6707

This functional instruction cannot use the local

symbol.

E:E-6708 The symbol is undefined.

13.2.6 Message Editing

Error code Message Cause/action

G:E-6000 Specify A address. Specify an A address like A0.0.

G:E-6001 Illegal address data.

The characters you can use for addressing are the letter A,

a period (.), and digits 0 to 9.

G:E-6002 Illegal range data. The maximum allowed A address is exceeded.

G:W-7000 KANJI is not allowed

When the PMC model is PA3, full-size characters cannot

be used.

13.2.7 Print

Error code Message Cause/action

H:F-2005 Source program has wrong file

H:F-2008 Cannot open **** file

13.2.8 Compile

Error code Message Cause/action

I:F-2100 Not enough disk space

I:F-2101 Out of memory

I:E-3100 **** read error The source program could not be read.

I:E-3101 **** write error The results of compilation could not be written.

I:E-3102 **** Source program name illegal. An invalid source program name was specified.

I:E-3103 **** Source program not found. The **** source program is not found.

I:E-3104 **** file not found
