B-66234EN/05 5.COMPILATION AND DECOMPILATION

- 233 -

5.3 AUTOMATIC COMPILATION AND DECOMPILATION

This section describes automatic compilation and decompilation.

The automatic compilation or decompilation processing is performed

when the mode is switched between offline and online so that a source

program in a sequence program (LAD file) is consistent with the

object code (memory card-formatted data).

• Execution condition of automatic compilation

Select [Ladder] - [Online/Offline]. When the mode is switched

from offline to online, a source program is compiled

automatically under one of the following conditions.

⋅ When a source program (such as a title or ladder) is

changed

⋅ When a source program is imported

⋅ When a source program is not compiled after a sequence

program is created

⋅ When the time stamp of memory card-formatted data is

older than that of any data in a source program (when data

is converted)

• Execution condition of automatic decompilation

Select [Ladder] - [Online/Offline]. When the mode is switched

from online to offline, object code is decompiled automatically

under one of the following conditions.

⋅ When memory card-formatted data is loaded from the PMC

⋅ When a memory card-formatted file is imported

⋅ When a Handy File-formatted file is imported

⋅ When a ROM-formatted file is imported

⋅ When online editing is executed

⋅ When the time stamp of any data in a source program is

older than that of memory card-formatted data (when data is

converted)

NOTE

Setting options for automatic compilation or

decompilation

(1) Compile option

- Select [Tool] - [Option].

- Click the [Compile] tab for setting.

(2) Decompile option

- Select [Tool] - [Option].

- Click the [Decompile] tab for setting.
