FANUC LADDER-III

SUPPLEMENTARY OPERATOR’S MANUAL

01 05/03/29 First issue B-66234EN/05-2

EDIT

DATE

DESIG.

DESCRIPTION

23/39

TITLE

DRAW.NO.

SHEET

CUST.

4.3. Command Line Execution Function

Relate parameter of command line execution function was added to support the zero suppression

of the PMC address. Please refer to this chapter when you use additional function.

10.4.5 Converting the Source Program of an *.LAD File to a Mnemonic File

Converting the Source Program of an *.LAD File to a Mnemonic File.

10.4.5.1 Converting whole source program to one mnemonic file

SrcToMnemonic [/datatype= 0 | 1 | 2 | 5 | 6] [/mode=0 | 1| 2 | 3| 4 ]

[/separate] [/zerosup] [/file=[Drive:][Path]file name]

Parameter

/datatype =0:

Converts all source programs.(defalut)

=1:

Converts only system parameters.

=2:

Converts only title data.

=5:

Converts only I/O module data.

=6:

Converts only message data.

/mode =0:

Converts data to P-G compatible data.(defalut)

=1:

Converts data with in full option mode.

=2:

Converts data to label/subprogram format data.

=3:

Converts data to Japanese comment format data.

=4:

Converts data to extended function format data.

* An error occurs and interrupts processing, when not corresponding to extended

function.

/separate

Output data by dividing into the program unit or data kind.The character string

which means the data type is added to the output file name.

/zerosup

The zero suppression is applied to the PMC address. ("R0000.0" is output as "R0.0")

/file =[Drive:][Path]file name:

Specify the file name of a mnemonic file to be converted.

When /separate is specified, the character string which means the data type is

automatically added to the output file name.

(e.g.) When file name is ".txt"

"SYSPRM.txt","TITLE.txt","SYMBOL.txt","LEVEL1.txt",...

Explanation

Source programs of the LAD file opened by command “FlOpen” are converted to

the specified mnemonic file.

"10.4.5 Converting the Source Program of an *.LAD File to a Mnemonic File" is updated.
