Operators manual
FANUC LADDER-III
SUPPLEMENTARY OPERATOR’S MANUAL
01 05/01/14 First issue B-66234EN/05-1
EDIT
DATE
DESIG.
DESCRIPTION
3/69
TITLE
DRAW.NO.
SHEET
CUST.
1. Outline
The FANUC PMC programming tool “FANUC LADDER-III“ has been revised as listed below.
Contents of change
-
Copy/paste of ladder diagram between different PMC types
-
Ladder program difference display function
-
Dividing mnemonic file by conversion
-
Transferring multi-language PMC message data to PMC and writing into F-ROM
-
Addition of control data for extra relay (E)
This manual is a supplementary manual for the above “Contents of change”.
Other explanations (existing functions, operation, etc.) are described in the following manual.
Name of Manual Spec.No.
FANUC LADDER-III OPERATOR'S MANUAL B-66234EN
2. Applied Software
The contents of change described herein apply to the following software.
FANUC LADDER-III
Name Specification Version
FANUC LADDER-III A08B-9210-J505 4.80 or later
FANUC LADDER-III Upgrade A08B-9210-J506 4.80 or later
CNC System software
Software Drawing number Series Edition
Series 30i/ 300i/ 300is-MODEL A
CNC System Software
A02B-0303-H501#G002
A02B-0303-H501#G012
A02B-0303-H501#G022
G002
G012
G022
6.1 or later
Series 31i/ 310i/ 310is-MODEL A
CNC System Software
A02B-0307-H501#G101
A02B-0307-H501#G111
G101
G111
6.1 or later
Series 31i/ 310i/ 310is-MODEL A5
CNC System Software
A02B-0306-H501#G121
A02B-0306-H501#G131
G121
G131
6.1 or later
Series 32i/ 320i/ 320i-MODEL A
CNC System Software
A02B-0308-H501#G201 G201
6.1 or later
PMC Managing software
Software Drawing number Series Edition
Series 30i/ 31i/ 32i PMC System Software
A02B-0303-H580#40A0 40A0 06 or later
