11.EXTENDED SYMBOL/COMMENT FUNCTION B-66234EN/05

- 410 -

Source conversion

In the processing that converts the mnemonic into the source file, if

the following conditions are fulfilled, the symbol will be defined

automatically.

• The undefined symbol is inputted as the label of the JMPB/

JMPC/ LBL instruction.

• The identification code of the mnemonic is "%@3-D".

%@3-D

・・・

RD Input

JMPB abc

abc LBL

zyx LBL

・・・

%P1 SP

RD Input

JMPC zyx

・・・

Fig. 11.3.9(c) Mnemonic

Compile

L address of the symbol is assigned.

Operation

1. Select [Tool]-[Compile...]. Then, the [Compile] dialog appears.

2. Click the <Exec> button.

3. The L address is assigned.

NOTE

1 You can define the new label on the offline editing

screen.

2 You cannot define the new label on the online

editing screen. But, you can use the already

defined symbol.

3 You can input the symbol of only LABEL type as

the label of the JMPB/JMPC/LBL instructions.

4 If assigned L address is displayed on the symbol

comment edit display, the "*" mark adheres to the

head of the address.

5 When the automatic assignment area becomes

empty, the error occurs, and compile processing is

stopped.

6 L address is assigned without regard to the setting

of "Automatic Assignment Address" on the system

parameter screen.

If the symbol "abc" is not defined, it is

defined automatically into the symbol

comment data.
