13.ERROR MESSAGES B-66234EN/05

- 460 -

Error code Message Cause/action

**** file cannot execute.

K:E-3100

The file cannot be executed.

The data of **** is broken.

K:E-3101

* Symbol & Comment data broken.

K:E-3102 Cannot be handle data type '%@2-C'.

When the format of %%%FLSET.CNF is FORMAT-A/B, the

mnemonic of the extended symbol %@2-C was converted.

Cannot convert files of the PMC series set up

the system.

K:E-3103

The model set with the system cannot be

converted.

K:E-3104 Cannot overwrite existing data.

K:E-3105 Cannot specify bit address of parameter.

A bit address was specified in a byte address parameter of

a function instruction.

K:E-3106

Cannot specify byte address on basic

instruction.

A byte address was specified in a basic instruction.

K:E-3107 Cannot specify output module at input address.

An output module is specified at the input address of I/O

module data.

K:E-3108 Cannot specify input module at output address.

An input module is specified at the output address of I/O

module data.

K:E-3109

Cannot specify the address prohibited using as

parameter.

A parameter prohibition address was specified in the

address parameter of a function instruction.

K:E-3110 Cannot specify the bit address.

K:E-3111 Cannot specify the byte address.

K:E-3112 Cannot specify the input address.

An output prohibition address was specified in the output

address parameter of a function instruction.

K:E-3113 Cannot specify the input address with coil. An output prohibition address was specified for a coil.

K:E-3114 Cannot specify the odd address.

An odd-numbered prohibition address was specified as an

odd-numbered address.

K:E-3117 Expected a multiple of 2.

A system parameter includes a numeric value that is not a

multiple of 2.

K:E-3118 Expected a multiple of 5.

A system parameter includes a numeric value that is not a

multiple of 5.

K:E-3119 Expected address. A basic instruction has no address.

K:E-3120 Expected function number.

K:E-3121 Expected parameter(s). A function instruction has no parameter.

K:E-3122

The identification code is not found in

mnemonic file.

K:E-3123 Illegal address.

An invalid address was specified as a symbol/ comment

data/message setting address.

K:E-3124 Illegal address in data table.

An invalid address was specified in the data table of a

function instruction.

K:E-3125 Illegal address of parameter.

An invalid address was specified in the address parameter

of a function instruction.

K:E-3126 Illegal character(s).

Invalid character data is contained in a system parameter,

title data, symbol/comment data, or message data.

Illegal Source-program name.

K:E-3127

The specified source program name is illegal.

The specified mnemonic file name is illegal.

K:E-3128

Illegal Mnemonic file name.

Illegal parameter number.

K:E-3129

Illegal title number.

An invalid data number was specified in a system

parameter.

K:E-3130 Illegal value of parameter. An invalid data number was specified as a data identifier.
