B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 97 -

NOTE

1 In advanced preview control and AI advanced

preview control modes, parameter No. 1774

cannot be used.

2 To perform bell-shaped acceleration/deceleration,

set the following parameter:

AI advanced preview control and AI contour

control: Bit 6 (RBL) of parameter No. 1603 = 1

3 When acceleration/deceleration before

interpolation is set for rapid traverse, linear

interpolation type positioning is performed.

When the following parameters are set,

acceleration/deceleration before interpolation is

performed:

AI advanced preview control and AI contour

control: Bit 1 (AIR) of parameter No. 7054 = 0

Alternatively, bit 1 (LRP) of parameter No. 1401 =

1 and bit 1 (AIR) of parameter No.7054 = 1

1775 (Must not be used)*(Always set 0.)

1776 (Must not be used)*(Always set 0.)

1777

Minimum speed for the automatic corner deceleration function (for advanced

preview control, AI advanced preview control, or AI contour control)

[Data type] Word

[Unit of data, valid data range]

Valid data range

Increment system Unit of data

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Set a speed at which the number of buffered pulses in deceleration is

assumed to be 0 when linear acceleration/deceleration before

interpolation is used.

1779

Critical angle subtended by two blocks for automatic corner deceleration (for

advanced preview control, AI advanced preview control, or AI contour

control)

[Data type] 2-word

[Unit of data] 0.001 deg

[Valid data range] 0 to 180000

Set a critical angle to be subtended by two blocks for corner

deceleration when the angle-based automatic corner deceleration

function is used.

The angle subtended by two blocks is defined as q in the examples

shown below.
