B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 265 -
5300 Tapping axis in-position width in rigid tapping
5301 Spindle in-position width in rigid tapping
[Data type] Word
[Unit of data] Detection unit
[Valid data range] 0 to 32767
These parameters are used to set tapping axis and spindle in-position
widths in rigid tapping.
NOTE
1 If an excessively large value is specified, the
threading precision will deteriorate.
2 When rigid tapping is performed using the second
spindle
• When the SPR parameter (bit 1 of parameter
No.5204) is set to 0, the settings of parameter
No.5300 and No.5301 are applied to the second
spindle, as well as to the first spindle.
• When the SPR parameter (bit 1 of parameter
No.5204) is set to 1, the settings of parameters
No.5302 and No.5303 are applied to the second
spindle.
5302 Tapping axis in-position width in rigid tapping using the second spindle
5303 Spindle in-position width in rigid tapping using the second spindle
[Data type] Word
[Unit of data] Detection unit
[Valid data range] 0 to 32767
These parameters are used to set spindle and tapping axis in-position
widths in rigid tapping using the second spindle.
NOTE
These parameters are enabled when the SPR
parameter (bit 1 of parameter No.5204) is set to 1.
5308 In-position width at point R in rigid tapping (tapping axis)
[Data type] Word
[Unit of data] Detection unit
[Valid data range] 0 to 32767
This parameter is used to set the tapping axis in-position width at
point R in rigid tapping.
