0i/0i Mate - Model C Parameter manual Page 94

Parameter manual
4.DESCRIPTION OF PARAMETERS B-64120EN/01
- 82 -
1: Bell-shaped acceleration/deceleration.
NOTE
Bit 4 (PRT) of parameter No. 1603 is invalid.
BEL In the AI contour control mode:
0 : Linear acceleration/deceleration before look-ahead interpolation
is used.
1 : Bell-shaped acceleration/deceleration before look-ahead
interpolation is used.
#7 #6 #5 #4 #3 #2 #1 #0
1604
DS2
[Data type] Bit
DS2 When an overtravel alarm is issued for stored stroke check 2 during
linear acceleration/deceleration before interpolation, the function to
perform deceleration in advance so that the feedrate set in parameter
No. 12700 can be attained at the issuance of the alarm is:
0 : Disabled.
1 : Enabled.
#7 #6 #5 #4 #3 #2 #1 #0
JGLx CTLx
1610
JGLx CTBx CTLx
[Data type] Bit axis
CTLx Acceleration/deceleration in cutting feed including feed in dry run
0 : Exponential acceleration/deceleration is applied.
1 : Linear acceleration/deceleration after interpolation is applied.
NOTE
To use bell-shaped acceleration/deceleration after
interpolation, set this parameter to 0 and select the
acceleration/deceleration using CTBx, bit 1 of
parameter No.1610.
Parameter
CTBx CTLx
Acceleration/deceleration
0 0 Exponential acceleration/deceleration
0 1 Linear acceleration/deceleration after interpolation
1 0
Bell-shaped acceleration/deceleration after
interpolation
CTBx Acceleration/deceleration in cutting feed including feed in dry run
0 : Exponential acceleration/deceleration or linear acceleration/
deceleration after interpolation is applied (depending on the
setting in CTLx, bit 0 of parameter No.1610).
