B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 291 -

#7 #6 #5 #4 #3 #2 #1 #0

SQC

6005

ADR SQC

NOTE

When this parameter has been set, the power must

be turned off before operation is continued.

[Data type] Bit

SQC Calling a subprogram with its sequence number by the subprogram

call function is:

0 : Disabled.

1 : Enabled.

ADR Calling a subprogram with address E by the subprogram call function

using a custom macro and macro executor special code is:

0 : Disabled.

1 : Enabled.

Address E can be set for parameters Nos. 6090 and 6091.

#7 #6 #5 #4 #3 #2 #1 #0

MLG

6006

MMG MLG

[Data type] Bit

MLG In conditional decision statements in custom macros, logical

operations:

0 : Cannot be used.

1 : Can be used.

MMG With system variables (#4001 to #4022) for reading modal

information:

0 : Modal information specified in the previous blocks up to the

immediately preceding one can be read.

1 : Modal information of the currently executed block can be read.
