0i/0i Mate - Model C Parameter manual Page 85

Parameter manual
B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 73 -
1442 Maximum feedrate 2 of manual handle feed for each axis
[Data type] Word axis
[Unit of data, valid data range]
Valid data range
Increment system Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 6 to 15000 6 to 12000
Inch machine 0.1 inch/min 6 to 6000 6 to 4800
Rotation axis 1 deg/min 6 to 15000 6 to 12000
Set the maximum feedrate of manual handle feed for each axis.
1443 External deceleration rate 3 of cutting feed
[Data type] Word
[Unit of data, valid data range]
Valid data range
Increment system Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 6 to 15000 6 to 12000
Inch machine 0.1 inch/min 6 to 6000 6 to 4800
Set the external deceleration rate of cutting feed.
1444 External deceleration rate 3 of rapid traverse for each axis
[Data type] Word axis
[Unit of data, valid data range]
Valid data range
Increment system Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 6 to 15000 6 to 12000
Inch machine 0.1 inch/min 6 to 6000 6 to 4800
Rotation axis 1 deg/min 6 to 15000 6 to 12000
Set the external deceleration rate of rapid traverse for each axis.
1445 Maximum feedrate 3 of manual handle feed for each axis
[Data type] Word axis
[Unit of data, valid data range]
Valid data range
Increment system Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 6 to 15000 6 to 12000
Inch machine 0.1 inch/min 6 to 6000 6 to 4800
Rotation axis 1 deg/min 6 to 15000 6 to 12000
Set the maximum feedrate of manual handle feed for each axis.
