B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 137 -

4.16 PARAMETERS OF DI/DO

#7 #6 #5 #4 #3 #2 #1 #0

MHI ZPO RWM

3001

MHI RWM

[Data type] Bit

RWM RWD signal indicating that rewinding is in progress

0 : Output only when the tape reader is being rewound by the reset

and rewind signal RRW

1 : Output when the tape reader is being rewound or a program in

memory is being rewound by the reset and rewind signal RRW

ZPO The reference position return completion signal for G28 and G30 is:

0 : Output upon completion of the reference position return

operation.

1 : Output when the machine is positioned at the reference position

after the completion of the reference position return operation.

NOTE

If this parameter is set to 0, executing G28 or G30

outputs the reference position return completion

signal even when the reference position return

operation is performed in the machine lock state.

MHI Exchange of strobe and completion signals for the M, S, T, and B

codes

0 : Normal

1 : High-speed

#7 #6 #5 #4 #3 #2 #1 #0

3002 IOV

[Data type] Bit

IOV For the feedrate override signal and rapid traverse override signal:

0 : Negative logic is used.

1 : Positive logic is used.

#7 #6 #5 #4 #3 #2 #1 #0

MVG MVX DEC DAU DIT ITX ITL

3003

MVX DEC DIT ITX ITL

[Data type] Bit

ITL Interlock signal

0 : Enabled

1 : Disabled

ITX Interlock signals for each axis

0 : Enabled

1 : Disabled
