4.DESCRIPTION OF PARAMETERS B-64120EN/01

- 260 -

5241 Maximum spindle speed in rigid tapping (first-stage gear)

5242 Maximum spindle speed in rigid tapping (second-stage gear)

5243 Maximum spindle speed in rigid tapping (third-stage gear)

Maximum spindle speed in rigid tapping (fourth-stage gear)

5244

Maximum spindle speed in rigid tapping using the second spindle

(first-stage gear)

5245

Maximum spindle speed in rigid tapping using the second spindle

(second-stage gear)

5246

[Data type] 2-word

[Unit of data] min

-1

[Valid data range] The setting range is determined according to the spindle to position

coder gear ratio as follows:

Spindle : Position coder Setting range

1 : 1 0 to 7400

1 : 2 0 to 9999

1 : 4 0 to 9999

1 : 8 0 to 9999

Each of these parameters is used to set a maximum spindle speed for

each gear in rigid tapping.

NOTE

1 For the M series, set the same value for both

parameter No.5241 and parameter No.5243 for a

one-stage gear system. For a two-stage gear

system, set the value specified for parameter No.

5241 or 5242, whichever is greater, for parameter

No. 5243. Otherwise, P/S alarm No.200 will be

issued.

2 When rigid tapping is performed using the second

spindle

• When the SPR parameter (bit 1 of parameter

No.5204) is set to 0, the settings of parameters

No.5241 and No.5242 are applied to the second

spindle, as well as to the first spindle.

• When the SPR parameter (bit 1 of parameter

No.5204) is set to 1, the settings of parameters

No.5245 and No.5246 are applied to the second

spindle.
