0i/0i Mate - Model C Parameter manual Page 347

Parameter manual
B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 335 -
7183 First butting feedrate in butt-type reference position setting
[Data type] Word axis
[Unit of data, valid data range]
Valid data range
Increment system Units of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 30 to 15000 30 to 12000
Inch machine 0.1 inch/min 30 to 6000 30 to 4800
When the butt-type reference position setting is used, this parameter
sets the feedrate first used to hit the stopper on an axis.
7184 Second butting feedrate in butt-type reference position setting
[Data type] Word axis
[Unit of data, valid data range]
Valid data range
Increment system Units of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 30 to 15000 30 to 12000
Inch machine 0.1 inch/min 30 to 6000 30 to 4800
When the butt-type reference position setting is used, this parameter
sets the feedrate used to hit the stopper on an axis for a second time.
7185
Withdrawal feedrate (common to the first and second butting operations) in
butt-type reference position setting
[Data type] Word axis
[Unit of data, valid data range]
Valid data range
Increment system Units of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 30 to 15000 30 to 12000
Inch machine 0.1 inch/min 30 to 6000 30 to 4800
When the butt-type reference position setting is used, this parameter
sets the feedrate used for withdrawal along an axis after the
mechanical stopper has been hit.
7186 Torque limit value in butt-type reference position setting
[Data type] Byte axes
[Unit of data] %
[Valid data range] 0 to 100
This parameter sets a torque limit value in butt-type reference position
setting.
NOTE
When 0 is set in this parameter, 100% is assumed.
