B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 321 -

4.37 PARAMETERS OF POSITION SWITCH FUNCTIONS

#7 #6 #5 #4 #3 #2 #1 #0

PCM EPS IGP

6901

PSF PCM EPS IGP

[Data type] Bit

IGP During follow-up for the absolute position detector, position switch

signals are:

0 : Output

1 : Not output

EPS The number of position switches is:

0 : Up to 10.

1 : Up to 16.

PCM Position switch signals are output:

0 : Without considering acceleration/deceleration and servo delay.

1 : With considering acceleration/deceleration and servo delay.

PSF In advanced preview control mode, AI advanced preview control

mode, or AI contour control mode, position switches are:

0 : Not used.

1 : Used.

NOTE

The position switch signals are output considering

acceleration/deceleration after interpolation and

servo delay. Acceleration/deceleration after

interpolation and servo delay are considered even

for position switch signal output in a mode other

than advanced preview control mode, AI advanced

preview control mode, and AI contour control

mode. When this parameter is set to 1, however,

signals are output from the position switches at

different times from the specified ones.
