B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 77 -

1465

Virtual radius for feedrate control about rotation axis

[Data type] 2-word axis

[Unit of data]

Increment system IS-A IS-B IS-C Unit

Metric input mm

Inch input

0.01 0.001 0.0001

inch

[Valid data range] 0 to 99999999

Set the radius of a virtual circle when using such a control method that

the feedrate of a rotation axis is converted to a travel speed on a circle

of a virtual radius.

NOTE

1 Note that the increment system remains

unchanged regardless of whether metric input or

inch input is used.

2 This function is enabled when bit 0 (ROTx) of

parameter No. 1006 and bit 0 (RFDx) of parameter

No. 1408 are set to 1.

3 Be careful when setting bit 0 (RFDx) of parameter

No. 1408 and parameter No. 1465 (virtual radius).

In particular, when this function is used with a small

virtual radius value, axis movement speeds up.

4 If a large value is set for the amount of travel and

parameter No. 1465 (virtual radius), an alarm (P/S

5307: Internal data exceeded an allowable range.)

is issued.

5 This function cannot be used in the following

modes:

Rapid traverse, inverse time feed (G93), feed per

revolution (G94), threading, AI advanced preview

control, AI contour control
