B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 67 -
1423 Feedrate in manual continuous feed (jog feed) for each axis
[Data type] Word axis
(1) In M series, or in T series when JRV, bit 4 of parameter No.1402,
is set to 0 (feed per minute), specify a jog feedrate at feed per
minute with an override of 100%.
[Unit of data, valid data range]
Valid data range
Increment system Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 6 to 15000 6 to 12000
Inch machine 0.1 inch/min 6 to 6000 6 to 4800
Rotation axis 1 deg/min 6 to 15000 6 to 12000
(2) When JRV, bit 4 of parameter No.1402, is set to 1 (feed per
revolution) in T series, specify a jog feedarate (feed per
revolution) under an override of 100%.
[Unit of data, valid data range]
Increment system Unit of data Valid data range
Millimeter machine 0.01 mm/rev
Inch machine 0.001 mm/rev
Rotation axis 0.01 deg/rev
0 to 32767
1424 Manual rapid traverse rate for each axis
[Data type] 2-word axis
[Unit of data, valid data range]
Valid data range
Increment system Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 30 to 240000 30 to 100000
Inch machine 0.1 inch/min 30 to 96000 30 to 48000
Rotation axis 1 deg/min 30 to 240000 30 to 100000
Set the rate of manual rapid traverse when the rapid traverse override
is 100% for each axis.
NOTE
If 0 is set, the rate set in parameter 1420 is
assumed.
1425 FL rate of the reference position return for each axis
[Data type] Word axis
[Unit of data, valid data range]
Valid data range
Increment system Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 6 to 15000 6 to 12000
Inch machine 0.1 inch/min 6 to 6000 6 to 4800
Rotation axis 1 deg/min 6 to 15000 6 to 12000
Set feedrate (FL rate) after deceleration when the reference position
return is performed for each axis.
