B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 143 -

4.17 PARAMETERS OF DISPLAY AND EDIT (1 OF 2)

#7 #6 #5 #4 #3 #2 #1 #0

3100 COR CEM

[Data type] Bit

CEM On screens such as the operation history screen and help screen, keys

on the MDI panel are indicated:

0 : In English.

1 : With graphics qualifying for CE marking. (A character generator

supporting graphics qualifying for CE marking is required.)

COR Display

0 : Monochrome display

1 : Color display

NOTE

When using the 8.4" LCD, set this bit to 1.

#7 #6 #5 #4 #3 #2 #1 #0

3101 BGD KBF

[Data type] Bit

KBF When the screen or mode is changed, the contents of the key-in buffer

are:

0 : Cleared.

1 : Not cleared.

NOTE

When KBF = 1, the contents of the key-in buffer

can all be cleared at one time by pressing the

key followed by the key.

BGD In background editing, a program currently selected in the foreground:

0 : Cannot be selected. (BP/S alarm No.140 is issued disabling

selection.)

1 : Can be selected. (However, the program cannot be edited, only

displayed.)
