B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 107 -

NOTE

When an encoder with absolute address reference

marks (linear scale or rotary encoder) or encoder

with the absolute address zero point (linear scale

or rotary encoder) (detection circuit C) (closed loop

system) is used, set bit 1 (OPTx) of parameter No.

1815 to 1. When a linear scale with the absolute

address zero point (detection circuit C) (linear

motor system) is used, however, set OPTx to 0.

DCRx As an encoder with absolute address reference marks:

0 : A linear scale with absolute address reference marks is used.

1 : A rotary encoder with absolute address reference marks is used.

NOTE

1 Set bit 2 (DCLx) of parameter No. 1815 to 1.

2 When a rotary encoder with the absolute address

zero point (detection circuit C) is used, set this

parameter to 0.

APZx Machine position and position on absolute position detector when the

absolute position detector is used

0 : Not corresponding

1 : Corresponding

NOTE

When an absolute position detector is used, after

primary adjustment is performed or after the

absolute position detector is replaced, this

parameter must be set to 0, power must be turned

off and on, then manual reference position return

must be performed. This completes the positional

correspondence between the machine position and

the position on the absolute position detector, and

sets this parameter to 1 automatically.

APCx Position detector

0 : Other than absolute position detector

1 : Absolute position detector (absolute Pulsecoder)

For an absolute-position system using Inductosyn, set this

parameter to 1.

NRTx When the machine coordinate value on a rotation axis passes the

0-degree point or a point at which the machine coordinate value is

rounded off (360 degrees or the setting of parameter No. 1260):

0 : The zero point (parameter Nos. 1860 and 1861) is updated.

1 : The zero point (parameter Nos. 1860 and 1861) is not updated.

When a scale not maintaining speed data is used, set this parameter to
