0i/0i Mate - Model C Parameter manual Page 83

Parameter manual
B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 71 -
NOTE
1 To specify the maximum cutting feedrate for each
axis, use parameter No.1432 instead.
2 In a mode other than the look-ahead mode, the
maximum cutting feedrate specified in parameter
No.1422 or No.1430 is applied and the feedrate is
clamped at the maximum feedrate.
Maximum cutting feedrate for each axis in the advanced preview control mode
1432
Maximum cutting feedrate for each axis in the AI advanced preview control / AI
contour control mode or advanced preview control mode
[Data type] 2-word axis
[Unit of data, valid data range]
Valid data range
Increment system Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 0 to 240000 0 to 100000
Inch machine 0.1 inch/min 0 to 96000 0 to 48000
Rotation axis 1 deg/min 0 to 240000 0 to 100000
Specify the maximum cutting feedrate for each axis in the AI
advanced preview control / AI contour control mode or advanced
preview control mode.
A feedrate for each axis is clamped during cutting feed so that it does
not exceed the maximum cutting feedrate specified for each axis.
NOTE
1 This parameter is effective only in linear and
circular interpolation. In polar coordinate and
cylindrical interpolation, the maximum feedrate for
all axes specified in parameter No.1431 is
effective.
2 If a setting for each axis is 0, the maximum
feedrate specified in parameter No.1431 is applied
to all axes and the feedrate is clamped at the
maximum feedrate.
3 In a mode other than the AI advanced preview
control / AI contour control mode or advanced
preview mode, the maximum cutting feedrate
specified in parameter No.1422 or No.1430 is
applied and the feedrate is clamped at the
maximum feedrate.
