0i/0i Mate - Model C Parameter manual Page 324

Parameter manual
4.DESCRIPTION OF PARAMETERS B-64120EN/01
- 312 -
6712 Total number of machined parts
The following parameter can be set at "Setting screen".
[Data type] 2-word
[Unit of data] One piece
[Valid data range] 0 to 99999999
This parameter sets the total number of machined parts.
The total number of machined parts is counted (+1) when M02, M30,
or an M code specified by parameter No.6710 is executed.
NOTE
The number of parts is not counted for M02, M03,
when bit 0 (PCM) of parameter No. 6700 is set to
1.
6713 Number of required parts
The following parameter can be set at "Setting screen".
[Data type] Word
[Unit of data] One piece
[Valid data range] 0 to 9999
This parameter sets the number of required machined parts.
Required parts finish signal PRTSF <F062#7> is output to PMC when
the number of machined parts reaches the number of required parts.
The number of parts is regarded as infinity when the number of
required parts is zero. The PRTSF <F062#7> signal is then not output.
6750 Integrated value of power-on period
The following parameter can be set at "Setting screen".
[Data type] 2-word
[Unit of data] min
[Valid data range] 0 to 99999999
This parameter displays the integrated value of power-on period.
6751 Operation time (integrated value of time during automatic operation) I
The following parameter can be set at "Setting screen".
[Data type] 2-word
[Unit of data] msec
[Valid data range] 0 to 60000
