0i/0i Mate - Model C Parameter manual Page 351

Parameter manual
B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 339 -
4.42 PARAMETERS OF PROGRAM RESTART
#7 #6 #5 #4 #3 #2 #1 #0
MOUMOA
7300
MOU MOA SJG
[Data type] Bit
SJG Return feedrate in program restart operation
0 : Dry run feedrate
1 : Jog feedrate
MOA In program restart operation, before movement to a machining restart
point after restart block search:
0 : The last M, S, T, and B codes are output.
1 : All M codes and the last S, T, and B codes are output.
NOTE
This parameter is enabled when the MOU
parameter is set to 1.
MOU In program restart operation, before movement to a machining restart
point after restart block search:
0 : The M, S, T, and B codes are not output.
1 : The last M, S, T, and B codes are output.
7310 Movement sequence to program restart position
The following parameter can be set at "Setting screen".
[Data type] Byte axis
[Valid data range] 1 to No. of controlled axes
This parameter sets the axis sequence when the machine moves to the
restart point by dry run after a program is restarted.
[Example]
The machine moves to the restart point in the order of the fourth,
first, second, and third axes one at a time when the first axis =
2, the second axis = 3, the third axis = 4, and the fourth axis = 1
are set.
