0i/0i Mate - Model C Parameter manual Page 205

Parameter manual

Page of 414

/ 414

B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 193 -

The spindle speed is limited to the upper limit of spindle speed

specified in parameter No. 3772, irrespective of the setting of this

parameter.

TSO During a threading or tapping cycle, the spindle override is:

0 : Disabled (tied to 100%).

1 : Enabled.

NOTE

During rigid tapping, the override is tied to 100%,

irrespective of the setting of this parameter.

#7 #6 #5 #4 #3 #2 #1 #0

THB MRS MSI RSC SAM

3709

SMC RSC

[Data type] Bit

SAM The sampling frequency to obtain the average spindle speed

0 : 4 (Normally, set to 0.)

1 : 1

RSC In the constant surface speed control mode, the surface speed of a

rapid traverse block is calculated:

0 : In accordance with the coordinates of the end point.

1 : In accordance with the current value, as in cutting feed.

MSI In multi-spindle control, the SIND signal is valid

0 : Only when the first spindle is valid (SIND signal for the 2nd, 3rd

spindle becomes ineffective)

1 : For each spindle irrespective of whether the spindle is selected

(Each spindle has its own SIND signal).

MRS When the S 12-bit code signals and actual spindle speed signals are

output in multi-spindle control:

0: Signals common to the first through second spindles are used.

In this case, information about a spindle selected by the spindle

selection signal (SWS1-SWS2<G027#0-#1>) is output.

1: Information about each of the first through third spindles is

output on individual signals.

Signal When MRS is set to 0

When MRS

is set to 1

S 12-bit code signals

R01O-R12O<F036,F037>

Actual spindle speed signals

AR0-AR15<F040,F041>

First spindle (SWS1 = 1)

Second spindle (SWS1 =

0, SWS2 = 1)

First spindle

S 12-bit code signals 2

R01O3-R12O2<F200,F201>

Actual spindle speed signals 2

AR200-AR215<F202,F203>

Second

spindle

NOTE

To use this parameter, the multi-spindle control

option and spindle serial output are required.

SMC The function to check a large S command is:
