B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 273 -

5365

Bell-shaped acceleration/deceleration time constant for the first spindle in

rigid tapping (first-stage gear)

5366

Bell-shaped acceleration/deceleration time constant for the first spindle in

rigid tapping (second-stage gear)

5367

Bell-shaped acceleration/deceleration time constant for the first spindle in

rigid tapping (third-stage gear)

[Data type] Word

[Unit of data] msec

[Valid data range] 0 to 512

These parameters are used to set bell-shaped acceleration/deceleration

time constants for the first spindle in rigid tapping.

5369

Bell-shaped acceleration/deceleration time constant for the second spindle

in rigid tapping (first-stage gear)

5370

Bell-shaped acceleration/deceleration time constant for the second spindle

in rigid tapping (second-stage gear)

[Data type] Word

[Unit of data] msec

[Valid data range] 0 to 512

These parameters are used to set bell-shaped acceleration/deceleration

time constants for the second spindle in rigid tapping.

5381

Override value during rigid tapping return

[Data type] Byte

[Unit of data] 1% or 10%

[Valid data range] 0 to 200

This parameter is used to set the override value during rigid tapping

return.

If the setting is 0, no override is applied.

NOTE

This parameter is valid when bit 4 (DOV) of

parameter No. 5200 is set to 1.

If bit 3 (OVU) of parameter No.5201 is set to 1,

10% is set as the units of data. Thus, an override

of up to 2000% can be applied during extraction.
