4.DESCRIPTION OF PARAMETERS B-64120EN/01

- 318 -

LFE When a tool life is specified by count:

0 : A count value from 0 to 9999 can be specified.

1 : A count value from 0 to 65535 can be specified.

#7 #6 #5 #4 #3 #2 #1 #0

TC1

6804

ETE TC1 E10

[Data type] Bit

E10 When the tool life is specified by time:

0 : The tool life is counted at intervals of 4 seconds.

1 : The tool life is counted at intervals of 10 seconds.

NOTE

This parameter is valid when bit 2 (LTM) of

parameter No. 6800 is set to 1.

TC1 During automatic operation, preset of the tool life counter is:

0 : Disabled.

1 : Enabled.

ETE In extended tool life management, as the mark indicating that the life

of the last tool in a group has expired:

0 : "@" is also used.

1 : "*" is used.

6810

Tool life management ignored number

[Data type] Word

[Valid data range] 0 to 9999

This parameter sets the tool life management ignored number.

When the set value is subtracted from a T code, a remainder is used as

the tool group number of tool life management when a value

exceeding the set value is specified in the T code.
