0i/0i Mate - Model C Parameter manual Page 73

Parameter manual

Page of 414

/ 414

B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 61 -

0: Performed at feed per minute.

1: Performed at feed per rotation.

NOTE

Specify a feedrate in parameter No.1423.

#7 #6 #5 #4 #3 #2 #1 #0

RTV MIF

1403

NOTE

When this parameter is set, the power must be

turned off before operation is continued.

[Data type] Bit

MIF Cutting feedrates at feed per minute is specified by F commands

0: In units of 1 mm/min for millimeter machines or 0.01 inches/min

for inch machines.

1: In unit of 0.001 mm/min for millimeter machines or 0.00001

inches/min for inch machines.

NOTE

M series are not equipped with this parameter.

Cutting feedrates are specified by F commands in

units of 0.001 mm/min for millimeter machines or

0.00001 inches/min for inch machines.

RTV Override while the tool is retracting in threading

0 : Override is effective.

1 : Override is not effective.

#7 #6 #5 #4 #3 #2 #1 #0

FC0 FRV F8A DLF HFC

1404

FC0 HCF FRV F8A DLF HFC

[Data type] Bit

HFC The feedrate for helical interpolation is:

0: Clamped so that the feedrates along an arc and linear axis do not

exceed the maximum cutting feedrate specified by parameter

(No.1422 or 1430).

1: Clamped so that the composite feedrate along an arc and linear

axis does not exceed the maximum cutting feedrate specified by

parameter (No.1422).

DLF After a reference position is set, manual reference position return

performed at:

0 : Rapid traverse rate (parameter No.1420)

1 : Manual rapid traverse rate (parameter No.1424)
