1. THREE–PATH COMPLEX
LATHE FUNCTION
B–63284EN/03
ADDITIONAL FUNCTIONS OF SERIES
BH1E/BH2E/BH3E AND BH1F/BH2F/BH3F
625
NC format machining programs for a three–path lathe are created and
stored tool posts 1, 2, and 3 separately. Therefore, the machining
programs for the tool posts are completely independent of each other.
Conversational format machining programs are created separately for
each of tool posts 1, 2, and 3 in each machining process, but they are all
managed together as one program.
When a conversational format machining program is selected, only
machining processes with tool posts 1, 2, and 3 included in the program
can be executed.
It is impossible to execute different machining programs for the
individual tool posts.
Conversational format machining programs perform machining
operation as shown below.
Conversational format program
Process 1: Tool post 1
Outer–surface bar machining
Process 2: Tool post 1
Outer–surface grooving
Process 3: Tool post 2
Machining of inner surface of bar
Process 4: Tool post 3
Outer–surface threading
Process 5: Tool post 3
Drilling
Processes are divided
into machining operations
in individual tool posts
Process 1: Tool post 1
Outer–surface bar machining
Process 2: Tool post 1
Outer–surface grooving
Program execution (tool post 1)
Program execution (tool post 2)
Program execution (tool post 3)
Process 3: Tool post 2
Machining of inner surface of bar
Process 4: Tool post 3
Outer–surface threading
Process 5: Tool post 3
Drilling
Programs for three–path complex lathes can be created in the same
manner as for conventional two–path lathes. The machining types that
can be created are the same as for the two–path lathes.
1.2.5
Creating Machining
Programs
1.2.5.1
Machining program
format (three–path lathe)
1.2.5.2
Program creation
