Manual Guide i Operators manual Page 366

Operators manual
Ed.
Date
Design
Description
Name
Draw.
FANUC MANUAL GUIDE i
(Series16i/18i/21i-MB/TB)
OPERATOR’S MANUAL
B-63874EN-1/02-3
Page
FANUC LTD.
21
/
64
3) Measurement Result List
・Display which measurement listed below is operated on measurement
result list.
Manual Measurement－Measurement of outside corner
Manual Measurement－Measurement of inside corner
Measurement Cycle－Measurement of outside corner (PROBE
Z-axis direction)
Measurement Cycle－Measurement of outside corner (PROBE
X-axis direction)
Measurement Cycle－Measurement of inside corner (PROBE
Z-axis direction)
Measurement Cycle－Measurement of inside corner (PROBE
X-axis direction)
・Work coordination type number stored a measured result, and macro
variable number are displayed.
4) Definition of outside corner angle and inside corner angel.
・Outside Corner Angle
Ａ
Work
A
Work
・Inside Corner Angle
A
Work
Ａ
Work
