5. OPERATION

'ARITE (PROCRAMER --> Handy File:

FiM( FORMT FILE t&ME : A:YDATACSAAlNE.PEX

Handy File FILE !iAME

: C:YSAllF'LE.:SF

:Specif! the floppy disk drive!

The following operations are performed on the CNC side.

@ Connect the CNC and Handy File, and insert the 3.5” floppy disk generated in step @ into

the Handy File.

5.6.8.2 PMC program transfer from the CNC to the personal computer

[Operation]

Connect the CNC and Handy File, and output the PMC program to a 3.5” floppy disk (MS-

DOS format).

The following operations are performed on the personal computer side.

Select [l/O] (input/output) from the main unit.

Select [FDCAS] (FLOPPY CASSETTE ADAPTER & Handy

menu.

Select [READ] (read (programmer <- FLOPPY CASSETTE

(See Fig. 5.6.7.1 (a).)

File) from the input/output

ADAPTER & Handy File)).

Convert the PMC program on a 3.5” floppy disk (Handy File format) generated in step 0 to

ROM format by specifying the following items and running the utility.

l Name of the Handy File format file

Specify the program name output in step 0, and the 3.5” floppy disk drive where the

floppy disk is inserted.

l Name of the ROM format file

Specify the filename to be assigned to the ROM format data generated by conversion.
