FAPT Ladder for PC Operators manual Page 310

Operators manual
FAPT LADDER OPERATOR’S
SUPPLEMENTARY MANUAL
(FOR PERSONAL COMPUTER)
01 98.06.22 Hanaoka Additioanl 3.5-inch FD version B-66131E/05-5
EDIT DATE DESIG.
DESCRIPTION
7/8
TITLE
DRAW.NO.
SHEET
CUST.
・Combination of diverse system floppy disks (2)
Software -JXXX Combinations of versions
PMC-SA/SB/SC/NB
/PA/QC
502 06.1 06.2 06.3 06.4 07.0
－09.0
(Note1)
PMC-N/NA 501 05.0 06.1 06.2 06.3
－07.0
(Note2)
－
PMC-L/M/P 500 05.0 06.1 06.2 06.3
－08.0
(Note3)
－
(Note1) 09.0 is for IBM PC/AT. If NEC PC98 series, this field is 07.0－08.9.
(Note2) 07.0 is for IBM PC/AT. If NEC PC98 series, this field is 06.3.
(Note3) 08.0 is for IBM PC/AT. If NEC PC98 series, this field is 06.3.
・Combinations of system floppy disks and module floppy disks (1)
Software -JXXX Combinations of versions
PMC-SA/SB/SC/NB
/PA/QC
502 01.1 02.0 03.0
－03.6
04.0
－04.2
05.0
－06.0
SA/PA MODULE
(PMC-SA1/SA2/SA3
/PA1/PA3)
603
－
01.0 02.0 02.1 03.0
－03.4
04.0
SB/SC MODULE
(PMC-SB/SB2/SB3
/SB4/SB5/SB6/SC
/SC3/SC4)
604 01.0 02.0 03.0 03.1
－03.2
04.0
－04.4
04.5
－04.6
QC MODULE
(PMC-QC)
605
－
01.0
NB MODULE
(PMC-NB/NB2)
606
－
