B-63484EN/05 3.CREATING AND EDITING SEQUENCE PROGRAMS

- 137 -

3.6.4 New Line Character, Numeric Data

The input method of New line character and Numeric data is decided

according to the input mode and the content of MSG_EDIT_VAL (the

setting in “%%%flset.cnf” file).

• The setting of MSG_EDIT_VAL in “%%%flset.cnf” file.

• Input method of New line character

New line character

Input mode MSG_EDIT_VAL

Input Display

<Enter> key

or @0A@

Japanese-language

input mode

<Enter> key •

@0A@ @0A@

Code input mode

@0A@ @0A@

• Input method of Numeric data

(a) Numeric data format

;==============================================================================

; Ladder Editing Package(Windows) Initial Setting File

; ( `key word =' <= 9characters )

;==============================================================================

;

~~~~~;

*S; ======== System Setup ========

~~~~~;

;

exparam=0;

;

LAD_FILE_COUNT=10

;

MSG_EDIT_VAL=1 Set ‘0’ or ‘1’(default) by the text editor.

;

~~~~~

%%%

ET.

[Ibid, ____ ]

Memory address that the numerical data is stored

The address must be of binary format.

Set the “bid” data after character ”I“:

b : Number of bytes (1, 2, or 4)

i : Number of digits in the integer part (0 to 8)

d : Number of digits in the fractional part (0 to 8)

(Example)

The following message includes 3 digits tool number at the spindle

and the offset data ( _ . __ ) for this tool. And these data are

contained in memory address of 2bytes:

SPINDLE TOOL No. = [I230, ____ ]

OFFSET DATA = [I212, ____ ]
