Open CNC (Ladder Editing Package, Windows) Operators manual Page 514

Operators manual

Page of 571

/ 571

FANUC OPEN CNC LADDER EDITING

PACKAGE (Windows) SUPPLEMENTARY

OPERATOR’S MANUAL

01 05/01/14 First issue B-63484EN/05-1

EDIT

DATE

DESIG.

DESCRIPTION

15/60

TITLE

DRAW.NO.

SHEET

CUST.

4. Ladder program difference display function

The editing ladder source program can be compared with another ladder source program. And the

result of comparison is displayed in ladder diagram.

3.13 Ladder program difference display function

This function compares each subprogram of the editing ladder source

program with each subprogram of the other ladder source program.

And the comparison result of each subprogram is displayed. (Please refer to

Fig. 3.13.1(d))

The different net can be confirmed by opening the subprogram. (Please refer

to Fig. 3.13.1(e))

Editing ladder source subprogram The other ladder source program

| -ST F0072.2 M30Reque G0007.2 |

*----||---*---||---*---||---*-------------------------*---()---*

| |SoftOper| | | ST* |

| F0072.0 | |M10to20R| |G1007.2 |

*----||---* *---||---* *---()---*

| ST | | ST*_2Pat|

| | | h |

| SaveUpPr| | |

*----||---* | |

| | |

| R0010.2 F0000.7 | |

*----||-------|/|--* |

| ProgramS OP |

| earchFor |

| |

| WindrTes ACT .--------.----------------. D0048.1 |

*----||------------*SUB51 |D0050 *------------()---*

| .--------.----------------. |

| |

| -ST F0072.2 M10to20R R9091.1 X0008.4 G0007.2 |

*----||---*---||---*---||---*---||---*---||---*-----*---()---*

| |SoftOper| | ON | -EMG | | ST* |

| F0072.0 | | |R9091.0 |G0043.0 | |G1007.2 |

*----||---* | *---||---*---||---* *---()---*

| ST | OFF | MD1* | ST*_2Pat|

| | | | h |

| KEEPST | |G0043.2 | |

*----||------------* *---||---* |

| | MD4* |

| | |

| R0010.2 F0000.7 | |

*----||-------|/|--* |

| ProgramS OP |

| earchFor |

| |

| WindrTes ACT .--------.----------------. D0038.1 |

*----||------------*SUB51 |D0040 *----------()---*

| .--------.----------------. |

| |

Fig. 3.13(a)

Supported PMC models

Supported

All

Insert after "3.12 CHECKING DUPLICATE COIL"

Compare
