Open CNC (Ladder Editing Package, Windows) Operators manual Page 205

Operators manual
B-63484EN/05 4.PRINTING SEQUENCE PROGRAMS
- 177 -
2 Set up the following print options on the Step Sequence Diagram
tab.
Page No.
Specify a start page number for step sequence printing (the
Initially value is 1).
Title
Specify a title for step sequence printing (the Initially value
is "Step Sequence Diagram").
Sub Title
Specify a subtitle for step sequence printing (the Initially
value is blank).
Print Program
Specify the step sequence programs you want to print (the
Initially value is <All>).
All: All programs (including subprograms) will be printed.
Unit: Enter the name of the subprogram you want to print,
or select it from the combo box.
Sub Program No. (Initially selected.)
3 To preview step sequence program printing, click the <Preview>
button.
4 To set up the print options, click the <OK> button.
To cancel the setup of the print options, click the <Cancel>
button.
The [Print] screen appears again.
5 To print, click the <OK> button.
To quit without printing, click the <Cancel> button.
