12.ERROR MESSAGES B-63484EN/05

- 396 -

Error code Message Cause/action

I:E-3314

LADDER program exists beyond END2

instruction.

END2 is the end instruction for the second level. After END2, no

instruction can be specified.

I:E-3315

LADDER program exists beyond END3

instruction.

END3 is the end instruction for the third level. After END3, no

instruction can be specified.

I:E-3316

LADDER program exists beyond END

instruction.

END is the end instruction for all ladder programs. After END, no

instruction can be specified.

I:E-3317 END1 instruction can not be used. The END1 instruction is used at a level other than the first level.

I:E-3318 END2 instruction can not be used.

The END2 instruction is used at a level other than the second

level.

I:E-3319 END3 instruction can not be used. The END3 instruction is used at a level other than the third level.

I:E-3320 END instruction can not be used. The END instruction is used at the first level.

I:E-3330 There is no COME instruction.

The COM instruction for starting a COM instruction control range

is defined, but the COME instruction for ending .the range is not

defined.

I:E-3331

CALL instruction can not be used in the

range controlled COM instruction.

A sub-program cannot be called from within a COM instruction

control range. So, the CALL instruction cannot be used.

I:E-3332

CALLU instruction can not be used in the

range controlled COM instruction.

A sub-program cannot be called from within a COM instruction

control range. So, the CALLU instruction cannot be used.

I:E-3333

Another COM instruction can not be used

in the range controlled COM instruction.

In a COM instruction control range, the COM instruction for

starting a control range is defined again.

I:E-3334

COME instruction must be the pair with

COM.

If a COM instruction control range is not started, the COME

instruction for ending a control range cannot be used.

I:E-3335

COME instruction is detected though the

case of the coil number specification.

If the end of a COM instruction control range is defined by

specifying the number of coils, the COME instruction for ending a

control range cannot be used.

I:E-3340 There is no JMPE instruction.

The JMP instruction for specifying a jump start position is defined,

but the JMPE instruction for specifying a jump end position is not.

I:E-3341

Another JMP instruction can not be used

in the range of JMP instruction.

Between a JMP instruction for specifying a jump start position

and a JMPE instruction for specifying a jump end position,

another JMP instruction is defined.

I:E-3342

JMPE instruction must be the pair with

JMP.

If the JMP instruction for specifying a jump start position is not

defined, the JMPE instruction for specifying a jump end position

cannot be used.

I:E-3343

JMPE instruction is detected though the

case of the coil number specification.

If a jump end position is defined by specifying the number of

coils, the JMPE instruction for specifying a jump end position

cannot be used.

I:E-3350 There is no label of ****.

The label **** for indicating the jump destination of a JMPB

instruction cannot be found.

I:E-3351 The label of **** is used twice or more.

At the jump destination of the LBL instruction, the same label

number **** is defined. Define a different label number.

I:E-3352 Too many labels.

The total number of LBL instruction jump destinations defined

exceeded the maximum allocable value of a selected type of

program. Reduce the number of jump destinations defined.

I:E-3353

The destination of JMPB instruction is

beyond COM/COME instruction.

The JMPB instruction cannot be used to make a jump from within

a COM instruction control range to an external point, or from a

point outside a COM instruction control range to a point within the

range. The JMPB instruction can only be used to make a jump

from one position to another both within a COM instruction control

range or outside a COM instruction control range.

I:E-3400 There is an undefined instruction.

A step sequence program includes an instruction that cannot be

handled by a selected type of program, or a destroyed instruction.

I:E-3420

Program number is different from

program name.

In a parameter of program start instruction SP, a program

number that does not match the file name is specified.
